Nom. Size Range
DN 25 - DN 200
Nom. Pressure Range
PN 10 - PN 16
Temperature Range
-10 °C up to +300 °C
Sealing
Gland Packing
key facts
-
Disc opening into the vessel
-
Outside Screw and Yoke
-
Non-Rising Handwheel
-
Rising Spindle

DESIGN
- Disc opening intp the vessel
- Outside Screw and Yoke
- Rising Spindle
- Non-Rising Handwheel
- Gland Packing
OPTIONS
- Live Loaded Packing
- Cone with flexible gasket (PTFE)
ADDITIONAL EQUIPMENT
- Electric Actuator
- Limit Switches
- Heating Jacket
- Chain Wheel
- Pneumatic Actuator
- Gearbox
CUSTOM MATERIALS
- 1.4408
- Further Materials upon Request
