Nom. Size Range
DN 15 - DN 200
Nom. Pressure Range
PN 10 - PN 160
Temperature Range
-200 °C up to +550 °C
Sealing
Gland Packing
key facts
-
Bolted Bonnet
-
Outside Screw and Yoke
-
Gland Packing
-
Rising Handwheel









DESIGN
- Slanted Seat
- Bolted Bonnet
- Outside Screw and Yoke
- Gland Packing
- Rising Handwheel
- Integral Seat
- Flanged
OPTIONS
- Position Indicator
- Balanced Plug
- Live Loaded Packing
- Heating Jacket
- Extended Bonnet
- Soft/Resilient Seated Disc
- Conical Disc
- Regulating Disc
ADDITIONAL EQUIPMENT
- Electric Actuator
- Limit Switches
- Chain Wheel
- Spindle Extensions
- Pneumatic Actuator
- Gearbox
CUSTOM MATERIALS
- 1.4308
- 1.4552
- 1.4408
- 1.4581
- 1.0619
- 1.5419
- 1.7357
- 1.7363
- Further Materials upon Request
Nom. Size Range
DN 15 - DN 200
Nom. Pressure Range
PN 10 - PN 40
Temperature Range
-200 °C up to +550
Sealing
Bellow Sealing
KEY FACTS
-
Bolted Bonnet
-
Outside Screw and Yoke
-
Primarily Sealing: Bellow Sealing, Secandary Sealing: Safety Gland Packing
-
Rising Handwheel

DESIGN
- Slanted Seat
- Bolted Bonnet
- Outside Screw and Yoke
- Primarily Sealing: Bellow Sealing, Secandary Sealing: Safety Gland Packing
- Rising Handwheel
- Integral Seat
- Flanged
OPTIONS
- Balanced Plug
- Heating Jacket
- Soft/Resilient Seated Disc
- Conical Disc
- Regulating Disc
ADDITIONAL EQUIPMENT
- Chain Wheel
- Gearbox
- Electric Actuator
- Pneumatic Actuator
- Limit Switches
- Spindle Extensions
CUSTOM MATERIALS
- 1.4308
- 1.4552
- 1.4408
- 1.4581
- 1.0619
- 1.5419
- 1.7357
- 1.7363
- Further Materials upon Request
