Nom. Size Range
DN 50 - DN 600
Nom. Pressure Range
PN 10 - PN 25
Temperature Range
-200 °C up to +550 °C
Sealing
Gland Packing
key facts
-
Outside Screw and Yoke
-
Non-Rising Handwheel
-
Obtruator: Double Disc
-
Integral Seat
DESIGN
- Outside Screw and Yoke
- Rising Spindle
- Non-Rising Handwheel
- Gland Packing
- Backseat
- Flanged
- Double Disc
OPTIONS
- Position Indicator
- Balanced Plug
- Live Loadede Packing
- Extended Bonnet
- Weld End Connections
- Bypass
ADDITIONAL EQUIPMENT
- Electric Actuator
- Gear
- Handwheel- and Remote Control
- Chain Wheel
- Pneumatic and Hydraulic Cylinder
CUSTOM MATERIALS
- 1.4308
- 1.4552
- 1.4408
- 1.4581
- 1.0619
- 1.5419
- 1.7357
- 1.7363
- Further Materials upon Request
Nom. Size Range
DN 50 - DN 600
Nom. Pressure Range
PN 10 - PN 25
Temperature Range
-200 °C up to +550 °C
Sealing
Gland Packing
key facts
-
Outside Screw and Yoke
-
Non-Rising Handwheel
-
Obtruator: Flexible Wedge
-
Integral Seat
DESIGN
- Outside Screw and Yoke
- Rising Spindle
- Non-Rising Handwheel
- Gland Packing
- Backseat
- Flanged
- Integral Seat
- Flexible Wedge
OPTIONS
- Position Indicator
- Balanced Plug
- Live Loaded Packing
- Extended Bonnet
- Weld End Connections
- Bypass
ADDITIONAL EQUIPMENT
- Electric Actuator
- Gear
- Handwheel- and Remote Control
- Chain Wheel
- Pneumatic and Hydraulic Cylinder
CUSTOM MATERIALS
- 1.4308
- 1.4552
- 1.4408
- 1.4581
- 1.0619
- 1.5419
- 1.7357
- 1.7363
- Further Materials upon Request
Nom. Size Range
DN 50 - DN 300
Nom. Pressure Range
PN 10 - PN 25
Temperature Range
-200 °C up to +550 °C
Sealing
Bellow Sealing
key facts
-
Outside Screw and Yoke
-
Non-Rising Handwheel
-
Obtruator: Flexible Wedge
-
Bellow Sealing with Safety Gland Packing
DESIGN
- Outside Screw and Yoke
- Rising Spindle
- Non-Rising Handwheel
- Bellow Sealing with Safety Gland Packing
- Flanged
- Integral Seat
- Flexible Wedge
OPTIONS
- Position Indicator
- Balanced Plug
- Weld End Connections
- Bypass
ADDITIONAL EQUIPMENT
- Electric Actuator
- Gear
- Handwheel- and Remote Control
- Chain Wheel
- Pneumatic and Hydraulic Cylinder
CUSTOM MATERIALS
- 1.4308
- 1.4552
- 1.4408
- 1.4581
- 1.0619
- 1.5419
- 1.7357
- 1.7363
- Further Materials upon Request
Nom. Size Range
DN 50 - DN 600
Nom. Pressure Range
PN 40 - PN 160
Temperature Range
-200 °C up to +550 °C
Sealing
Gland Packing
key facts
-
Outside Screw and Yoke
-
Non-Rising Handwheel
-
Obtruator: Double Disc
-
Integral Seat
DESIGN
- Outside Screw and Yoke
- Rising Spindle
- Non-Rising Handwheel
- Gland Packing
- Backseat
- Integral Seat
- Flanged
- Double Disc
OPTIONS
- Position Indicator
- Balanced Plug
- Live Loaded Packing
- Extended Bonnet
- Weld End Connections
- Bypass
ADDITIONAL EQUIPMENT
- Electric Actuator
- Gear
- Handwheel- and Remote Control
- Heating Jacket
- Chain Wheel
- Pneumatic and Hydraulic Cylinder
CUSTOM MATERIALS
- 1.4308
- 1.4552
- 1.4408
- 1.4581
- 1.0619
- 1.5419
- 1.7357
- 1.7363
- Further Materials upon Request
Nom. Size Range
DN 50 - DN 600
Nom. Pressure Range
PN 40 - PN 160
Temperature Range
-200 °C up to +550 °C
Sealing
Gland Packing
key facts
-
Outside Screw and Yoke
-
Non-Rising Handwheel
-
Obtruator: Flexible Wedge
-
Integral Seat
DESIGN
- Outside Screw and Yoke
- Rising Spindle
- Non-Rising Handwheel
- Gland Packing
- Backseat
- Integral Seat
- Flanged
- Flexible Wedge
OPTIONS
- Position Indicator
- Balanced Plug
- Live Loadede Packing
- Extended Bonnet
- Weld End Connections
- Bypass
ADDITIONAL EQUIPMENT
- Electric Actuator
- Gear
- Handwheel- and Remote Control
- Heating Jacket
- Chain Wheel
- Pneumatic and Hydraulic Cylinder
CUSTOM MATERIALS
- 1.4308
- 1.4552
- 1.4408
- 1.4581
- 1.0619
- 1.5419
- 1.7357
- 1.7363
- Further Materials upon Request
Nom. Size Range
DN 50 - DN 300
Nom. Pressure Range
PN 40 - PN 63
Temperature Range
-200 °C up to +550 °C
Sealing
Bellow Sealing
key facts
-
Outside Screw and Yoke
-
Non-Rising Handwheel
-
Obtruator: Flexible Wedge
-
Integral Seat
DESIGN
- Outside Screw and Yoke
- Rising Spindle
- Non-Rising Handwheel
- Bellow Sealing with Safety Gland Packing
- Integral Seat
- Flanged
- Flexible Wedge
OPTIONS
- Position Indicator
- Balanced Plug
- Weld End Connections
- Bypass
ADDITIONAL EQUIPMENT
- Electric Actuator
- Gear
- Handwheel- and Remote Control
- Chain Wheel
- Pneumatic and Hydraulic Cylinder
CUSTOM MATERIALS
- 1.4308
- 1.4552
- 1.4408
- 1.4581
- 1.0619
- 1.5419
- 1.7357
- 1.7363
- Further Materials upon Request
Nennweiten
DN 15 - DN 300
Druckstufen
PN 10 - PN 160
Temperaturbereich
-200 °C bis +550 °C
Abdichtung
Stopfbuchse
key facts
- Outside Screw and Yoke
- Rising Spindle
- Non-Rising Handwheel
- Gland Packing
- Backseat
TECHNISCHE DATEN
| Anschluss: | Flansche mit Dichtleiste nach DIN EN |
| Baugrößen: | PN 10-25 DN 50-600 |
| Baulängen: | PN 10-25 EN 558-1 Grundreihe 15 (DIN3202-F5) |
DESIGN
- Outside Screw and Yoke
- Rising Spindle
- Non-Rising Handwheel
- Gland Packing
- Backseat
WERKSTOFFE
| Gehäuse: | 1.0619, 1.7221, 1.4308, 1.4408, 1.4552, 1.4581 |
| Innenteile | 1.4021, 1.4541, 1.4571 |
Weitere Werkstoffe auf Anfrage
VARIANTEN
- Extended Bonnet
- Live Loaded Packing (TA-Luft 2002)
- Remote Control
- Gear
- Electric Actuator
- Body with Welding Ends
Nennweiten
DN 15 - DN 300
Druckstufen
PN 10 - PN 160
Temperaturbereich
-200 °C bis +550 °C
Abdichtung
Stopfbuchse
key facts
- Outside Screw and Yoke
- Rising Spindle
- Non-Rising Handwheel
- Gland Packing
- Backseat
TECHNISCHE DATEN
| Anschluss: | Flansche mit Dichtleiste nach DIN EN |
| Baugrößen: | PN 10-25 DN 50-600 |
| Baulängen: | PN 10-25 EN 558-1 Grundreihe 15 (DIN3202-F5) |
DESIGN
- Outside Screw and Yoke
- Rising Spindle
- Non-Rising Handwheel
- Gland Packing
- Backseat
WERKSTOFFE
| Gehäuse: | 1.0619, 1.7221, 1.4308, 1.4408, 1.4552, 1.4581 |
| Innenteile | 1.4021, 1.4541, 1.4571 |
Weitere Werkstoffe auf Anfrage
VARIANTEN
- Extended Bonnet
- Live Loaded Packing (TA-Luft 2002)
- Remote Control
- Gear
- Electric Actuator
- Body with Welding Ends
